Huggy™ 42-V2 Tent

UNICEF Standard - Fire Retardant

  • Key Features
    • Fire retardant, waterproof, rotproof & UV-stabilised

    • Can be used for schooling, storage or temporary shelter purposes

    • Lightweight, rectangular and framed tent

    • Outer tent fabric is made of 450 gsm - 550 gsm PVC coated fabric, 5000 mm

  • Dimensions
    Total size

    7.00 m x 6.00 m

    Centre height

    2.95 m

    Wall height

    2.10 m

    Centre height

    2.40 m

    Wall height

    1.95 m

  • Materials
    Outer tent

    450 gsm - 550 gsm fire retardant PVC coated fabric 5000 mm, natural white

    Inner tent

    120 gsm Polycotton, natural white

    Ground sheet

    190 gsm Polyethylene (HDPE), PE fabric, sewn in bathtub, light grey/natural white

    Windows

    Four windows long on each sidewall 0.90 m x 1.10 m reinforced with PVC strips / two windows on each short sidewall 0.85 m x 1.00 m reinforced with PVC strips

    Doors

    One door on each gable end side 1.20 m x 2.00 m, closed with Velcro

    Ground sheet

    Double stitched to inner tent, 100 mm - 200 mm above the ground

    Main frame

    46 aluminum pipes 36.90 mm diameter, 2 mm thick, silver / 15 steel connectors 42 mm diameter, 2 mm thick, silver / 14 steel connectors with base plates 42 mm diameter, 2 mm thick, silver / five hanging steel connectors 8 mm diameter, two hooks on each end, silver

    Seams

    All seams are double-stitched with welded main roof seams
