Huggy™ 72 Tent

UNICEF Standard - Fire Retardant

  • Key Features
    • Fire retardant, waterproof, rotproof & UV-stabilised

    • Can be used for schooling, storage or temporary shelter purposes

    • Lightweight, rectangular and framed tent

    • Outer tent fabric is made of 450 gsm - 550 gsm PVC coated fabric, 5000 mm

  • Dimensions
    Total size

    12.00 m x 6.00 m

    Centre height

    2.95 m

    Wall height

    2.10 m

    Centre height

    2.40 m

    Wall height

    1.95 m

  • Materials
    Outer tent

    450 gsm - 550 gsm fire retardant PVC coated fabric 5000 mm, natural white

    Inner tent

    120 gsm Polycotton, natural white

    Ground sheet

    190 gsm PVC coated fabric, sewn in bathtub, light grey/natural white

    Windows

    Six windows on each long sidewall 1.05 m x 1.10 m reinforced with PVC strips Two windows on each short sidewall 0.85 m x 1.00 m reinforced with PVC strips

    Doors

    One door on each gable end side 1.20 m x 2.00 m, closed with Velcro

    Ground sheet

    Double stitched to inner tent, 100 mm - 200 mm above the ground

    Main frame

    64 aluminum pipes 36.90 mm diameter, 2 mm thick, silver 21 steel connectors 42 mm diameter, 2 mm thick, silver 18 steel connectors with base plates 42 mm diameter, 2 mm thick, silver Seven hanging steel connectors 8 mm diameter, two hooks on each end, silver

    Seams

    All seams are double-stitched with welded main roof seams

  • Downloads

Videos

Key features video
Tent assembly video
HSNDS factory video
