Rex Hall – MSU 10.0 x 36m

Used by UNICEF/UNHCR

  • Key Features
    • Fast set up with four to six personnel without use of lifting equipment or working on heights

    • Made of durable aluminium box profiles and hot-dipped galvanised hardware, with covers of durable fire retardant and UV resistant translucent PVC fabric and fully HF welded for long life

    • Available in three sizes. Standard size 10 m width by 24 m, 32 m or 36 m length and large entry doors (sections of 4 m length can be added)

    • Designed to withstand high winds up to 31 m/s (<110 km/h) and can be used in both hot and cold climates

    • To watch the tent assembly video, visit www.vimeo.com/146239030.

  • Dimensions
    Standard size

    10 x 36 m

    Total area

    360 m²

    Main floor

    360 m²

    Centre height

    5.30 m

    Width

    10.00 m

    Ridge length

    36.00 m

    Side wall height

    3.35 m

    Total size

    4.50 m x 4.00 m

    Modular frame

    Aluminium box profiles 4.00 m - 5.50 m; Hot dipped galvanised steel apex, base plates and other components

  • Materials
    Outer tent

    Roof, wall, gable covers: 700 gsm PVC coated polyester, white, UV protected

    Ventilators

    The gable ends are fitted with high placed large ventilat

    Doors

    Both gable ends are fitted with lace up doors, 450 x 400 cm

    Modularity

    The length of the shelter can be endlessly extended with 10 x 4 m modules.

  • Downloads

Videos

Key features video
Tent assembly video
Rex Hall production video
