Woven Flexible Tarpaulin

ICRC/IFRC/MSF/Oxfam Standard

  • Key Features
    • Fire retardant (optional), waterproof, rotproof and UV-stabilised

    • Band reinforced tarpaulin in 4 m x 6 m sheets or 4 m x 60 m rolls developed by international research project and designed for long outdoor use in all climates

    • Woven high density polyethylene (HDPE) black fibres fabric laminated on both sides with low density polyethylene (LDPE) coating

    • Highly recommended for family shelter protection

  • Dimensions
    Size / sheet

    4.00 m x 6.00 m ±1

    Size / roll

    4.00 m x 60.00 m ±1

    Specific sheet without bands weight

    190 ± 20g under ISO 3801 (equivalent to 170 gsm min to 210 gsm max)

    Complete sheet with bands weight

    Plain sheet specific weight plus 10% additional weight for reinforcement bands under ISO 3801

    Total weight

    From 187 gsm min to 231 gsm max. Specific weight of bands from 150 gsm min to 200 gsm max

  • Materials
    Sheet / roll

    Woven HDPE black fibres fabric, double-side lamination with LDPE coating, reinforced with six bands of 75 mm width woven black HDPE fibres fabric and coated outside. Pre-punched 8 mm holes on the two side bands at 0.1 m +/-10% intervals, positioned in the centre of the bands (only the reinforcement bands are pre-punched, not the tarpaulin itself).

    Tensile strength

    Min 500 N, 15-25% elongation in warp and weft in plain sheet under ISO 1421-1

    UV resistance

    After 1500 hours UV under ASTM G53/94 (UVB 313 nm peak) minimum 80% of original value of the actual product and not less than 475 N

    Reinforcement bands

    Min 700 N as per ISO 1421-1, pulling lengthwise in a prepunched 8 mm hole with a hook of 8 mm wire diameter, at 200 mm from the end of the band. UV resistance 80% of original value and not less than 665 N.

    Welding

    Only one is allowed, lengthwise. The tarpaulin tensile strength crossways at the place of welding under ISO 1421-1 minimum 50% of original value and not less than 400 N
