Viva™ Family Tent

DFID / Save the Children Standard

  • Key Features
    • Fire retardant, waterproof, rotproof & UV-stabilised

    • 16m2 main floor area plus two 3.5m2 vestibules for a total area of 23 m2, double-fly with ground sheet

    • Complies to recommended minimum living area in hot & temperate climates (3.2m2 per person), providing extra space for cold climates

    • Suitable for families of 5 people

  • Dimensions
    Total living area

    23 m²

    Main floor

    16 m²

    Two vestibule areas

    3.5 m² x 2 = 7 m²

    Centre height

    2.20 m


    4.00 m

    Ridge length

    4.00 m

    Side wall height

    1.25 m

    Centre base length

    6.60 m

    Total size

    1.35 m x 1.40 m

    Door flaps

    1.45 m x 1.60 m

    Upper part

    1.45 m x 0.90 m (PC)

    Lower part

    1.45 m x 0.70 m (PVC)

  • Materials
    Fire retardancy

    Pass CPAI section 5 and 6 with maximum 10s after flame average and maximum 30s after flame per test piece; Ageing under ISO 4892-2, type A, 360 hours.

    Outer tent

    Roof, wall and canopy: 380 gsm without FR, Polycotton, natural white

    Inner tent

    380 gsm Polycotton, natural white

    Inner liner and partition

    160 gsm Polycotton, except fire retardant. Yellow, beige, cream and sand

    Mud flaps

    500 gsm - 610 gsm, PVC coated Polyester, in light colour

    Ground sheet

    180 gsm (HDPE), in light colour. Sewn in bathtub

  • Downloads


Key features video
Tent assembly video
Tent production video
