Rex Hall – MSU 10.0 x 32m

Used by ICRC/IFRC/WFP

Request a Sample Request a quote
  • Key Features

    • Fast set up with four to six personnel without use of lifting equipment or working on heights

    • Made of durable aluminium box profiles and hot-dipped galvanised hardware, with covers of durable fire retardant and UV resistant translucent PVC fabric and fully HF welded for long life

    • Available in three sizes. Standard size 10 m width by 24 m, 32 m or 36 m length and large entry doors (sections of 4 m length can be added)

    • Designed to withstand high winds up to 31 m/s (<110 km/h) and can be used in both hot and cold climates

    • To watch the tent assembly video, visit www.vimeo.com/146739313

  • Dimensions
    Standard size

    10 x 32 m

    Total area

    320 m²

    Main floor

    320 m²

    Centre height

    5.30 m

    Width

    10.00 m

    Ridge length

    32.00 m

    Side wall height

    3.35 m

    Total size

    4.50 m x 4.00 m

    Modular frame

    Aluminium box profiles 4.00 m - 5.50 m; Hot dipped galvanised steel apex, base plates and other components

  • Materials
    Outer tent

    Roof, wall, gable covers: 700 gsm PVC coated polyester, white, UV protected

    Ventilators

    The gable ends are fitted with high placed large ventilators with removable mosquito netting and adjustable rain flap

    Doors

    Both gable ends are fitted with sliding doors, 450 x 400 cm

    Modularity

    The length of the shelter can be endlessly extended with 10 x 4 m modules.

  • Downloads

Videos

Key features video
Tent assembly video
Rex Hall production video
