GeoHome

ICRC/IFRC/IOM Standard

  • Key Features
    • New generation family tent, geodesic shape

    • Adaptable to all climates

    • Easy-set up (15 minutes, 3 persons)

    • Fire retardant, UV resistant and waterproof

    • Accommodates five persons

    • Rapid deployment in any emergency.

  • Dimensions
    Total living area

    24.16 m2

    Centre height

    2.40 m

    Length

    4.33 m

    Width

    5.58 m

    Wall height

    Dome-shaped

    Door height

    1.80 m (1.7 m inner tent)

  • Materials
    Outer tent (roof, walls, mud flaps, ground sheets and share fly)

    Base fabric: Woven high-density polyethylene (HDPE) black fibres; Coating: white low density polyethylene (LDPE) on both sides 190 gsm; Fire retardancy: EN13823+AI

    Inner tent

    100% polyester, 110 gsm, white; Fire retardancy: CPAI 84

    Mosquito nets

    Polyester; Outer tent: 7-9 holes per inch2; Inner tent: 20-25 holes per inch2

    Frame

    All aluminium; Main pipes: outer diameter 19 mm +/- 0.5 mm, thickness 1.2 mm +/- 1%; Connectors: outer diameter adapted to main pipe, thickness 1.5 mm +/- 1%

  • Downloads

Videos

Key features video
Tent assembly video
Aerial overview of HSNDS factory
