Used by ICRC/IFRC/WFP/UNICEF/UNHCR
Rex Hall – MSU 10.0 x 24m
-
Key Features
Fast set up with four to six personnel without use of lifting equipment or working on heights
Made of durable aluminium box profiles and hot-dipped galvanised hardware, with covers of durable fire retardant and UV resistant translucent PVC fabric and fully HF welded for long life
Available in three sizes. Standard size 10 m width by 24 m, 32 m or 36 m length and large entry doors (sections of 4 m length can be added)
Designed to withstand high winds up to 31 m/s (<110 km/h) and can be used in both hot and cold climates
To watch the tent assembly video, visit www.vimeo.com/226868701.
-
Dimensions
Standard size
10 x 24 m
Total area240 m²
Main floor240 m²
Centre height5.30 m
Width10.00 m
Ridge length24.00 m
Side wall height3.35 m
Total size4.50 m x 4.00 m
Modular frameAluminium box profiles 4.00 m - 5.50 m; Hot dipped galvanised steel apex, base plates and other components
-
Materials
Outer tent
Roof, wall, gable covers: 700 gsm PVC coated polyester, white, UV protected
VentilatorsThe gable ends are ftted with high placed large ventilators with removable mosquito netting and adjustable rain fap
DoorsBoth gable ends are fitted with sliding doors, 450 x 400 cm
ModularityThe length of the shelter can be endlessly extended with 10 x 4 m modules
